T-ACE II+

Versatile

• Accommodates all Terumo Blood and Cell Technologies common bag systems, including top-and-bottom (TAB) and top-and-top (conventional) types, both with and without inline filters
• Performs a wide range of first- and second-separation processes; protocols include methods to produce red blood cells, platelet-rich plasma, platelet-poor plasma, buffy coat platelets, and platelet concentrate
• Provides added flexibility through 11 customizable programs; defines, adapts, and stores protocol parameters and powerful subroutines to meet your needs
• Offers special subroutines, such as air removal in filtered blood, aliquoting, buffy coat dilution, and more

Reliable and safe

• Automatically verifies the correct positioning of tubes, bags, frangible connectors, and fluid flow based on the selected protocol
• Guides operators step by step using a full-color, animated graphical display; provides schematic visualization of automated and microprocessor-controlled steps
• Actively indicates component flow and weight, clamp positions, and sealing functions using color changes
• Issues both an audible signal and a visual alert (operation indicator) when the process is complete or if errors occur
• Features a unique top-angled pneumatic press for a smooth start to extractions and enhanced layer stability
• Provides pure components through intelligent interaction of a flow regulator and 11 optical sensors

Precision where you need it most

The T-ACE II+ extractor is a master at component expression.

It is equipped with an internal microprocessor that monitors information from the scales and the optical and mechanical sensors integrated in the device. Using the information gathered, T-ACE II+  controls the pressure on the primary bag to direct the flow of blood components that are extracted.

The T-ACE II+ extractor works according to defined protocols. A wide set of parameters allows your blood center to customize and optimize protocols for different purposes to meet a wide range of customization needs.
